AG08 je 8-kanálový live streaming mixážny pult s dvomi fantómovými vstupmi pre kondenzátorové mikrofóny, integrovaným USB audio rozhraním, meničom hlasu a samplerom.
AG08 je 8-kanálový live streaming mixážny pult s dvomi fantómovými vstupmi pre kondenzátorové mikrofóny, integrovaným USB audio rozhraním, meničom hlasu a samplerom.
The AG08 is an 8-channel live streaming mixer featuring two phantom power inputs for condenser mics, an integrated USB audio interface, voice changer and sampler. By integrating more flexible I/O and USB routing options, expanded foot switch functionality, as well as additional DSP effects and improved internal circuitry for classleading sound, the AG08 is able to support an impressive depth of live streaming applications, as well as offline audio content creation. From single-user performances, to multiple personnel applications even on the scale of a full-blown variety show, the real-world, real-time functionality of the AG08 will leave your audience wanting more.
Features:
Input Channels | Mono[MIC/LINE] | 2 - CH1: Combo (Mic, +48 V phantom power / Line), 3.5 mm (1/8”) stereo mini (Headset mic, Plug-in power), CH2: Combo (Mic, +48 V phantom power / Guitar input / Line) *CH1 input and Headset mic cannot be used simultaneously |
---|---|---|
Stereo[LINE] | 3 - CH3/4: LR Stereo Phone, CH5/6: LR Stereo RCA/3.5 mm stereo mini (AUX), CH7/8: 4-pole mini in/out (TRRS) | |
AUX | 1 - Stereo mini | |
Smartphone | 1 - 4-pole mini input/output (TRRS) | |
USB | 1 - USB: 4 Stereo Audio Channels (Streaming, Voice, AUX, FROM DAW) | |
Output Channels | PHONES | 2 - CH1: 6.3 mm (1/4") Stereo / HEADSET mini PHONES *Cannot be used simultaneously, CH2: PHONES |
Smartphone | 1 - 4-pole mini input/output (TRRS) | |
MONITOR OUT | 2 - LR Stereo: XLR, 1/4 TRS Phone | |
STEREO OUT | 1 - MIX: LR stereo TRS Phone | |
USB | 1 - USB: 4 Stereo Audio Channels (Streaming, Voice, AUX, TO DAW), 8 Channels Direct Out *In Windows environment, ASIO channel and USB 2.0 exist independently. Please check the block diagram for details. | |
Bus | 4 Stereo | |
Functions | MUTE button x 5, CH1 FX preset button x 4, Sound pad x 6, +48 V phantom power x 2, GUITAR(HI-Z) x 1, PAD x 2, GAIN HIGH/LOW x 1, LINE/USB x 3, STREAMING ON/OFF x 3, CUE x 1, MIX MINUS (CH1, 2) | |
On-board processors | DSP | Voice Changer, Amp Simulator, COMP, EQ, REVERB (SPX Reverb), Delay, Ducker, Maximizer *Detail is operated on AG Controller |
USB | USB Audio | 8 IN / 14 OUT, USB Audio Class 2.0 Compliant, Sampling Frequency: Max. 48 kHz, Bit Depth: 24-bit, Type-C |
USB DC Power input | 1 - Type-C, 5 V DC, 1.5 A | |
General specifications | ||
Power requirements | DC 12 V, 1.5 A / USB-C 5 V, 1.5 A | |
Power consumption | Max. 7.5 W | |
Dimensions | W | 290 mm (11.5") |
H | 88 mm (3.5") | |
D | 222 mm (8.8") | |
Net weight | 2.2 kg (4.9 lbs) | |
Included Accessories | AC adapter PA-150B, USB2.0 Cable (1.5 m), Quick Guide, Safety Guide, Wavelab Cast Download Information, Cubase AI Download Information | |
Others | Operating Temperature: 0 to + 40 ℃ |
